Ron Freier wrote:

Has anyone tried, and succeded, in using a stock Mazda air pump to

run a directional

gyro and an

artificial horizon?
I'm trying to decide about going with all electric instruments.

PRICEY!!

Ron Freier
Vision 2+2 (under construction)

Dave Atkins and others have been runing smog pumps for years
to drive gyro instrments. Works great. A bit heavy at about 8 pounds.

Paul Lamar

One bad thing. When they fail, they lock up solid.
Bulent

They are very very reliable. Mine has 6, count them, 6 ball bearings.

Paul Lamar

Ron, I tried both aircraft vacuum pumps and the smog pump, the smog pump
worked better for me, the only downside being, as Paul mentioned, the
weight.  Mine weighs 5.6 lbs which is about 4 lbs more than a aircraft pump.
However, it provides sufficient vacuum at idle to erect the gyros which the
aircraft pump did not.

Ed Anderson
