The stock Mazda injectors (normally aspirated) are around 50 lb/hr.

One

builder got away with using 36 lb/hr parts but I wouldn't recommend

anything

less.  The EC2 can be used with either type (low or high impedance)

but a 5

ohm resistor in series must be used with the low impedance type.

(This is

what Mazda does too)

I used the diffusers on the primary injectors but not on the

secondaries.

Didn't seem to make any difference at high throttle where the

secondaries

kick in.

Tracy Crook
tcrook@rotaryaviation.com
www.rotaryaviation.com

OK - 36 lb injectors are expensive - $370 for a set of 8 at Summit.

42lb are $459 and 50lb are $600 at Downs Ford.

Ken P.

The pressure for these ratings is 38 PSI.  The Mustang Mags carry

several advertisers for these items.

Ken P.

Ken, if you think the set of 8 for $370 at Summit is expensive, try a set of
4 for $500 for brand-new Mazda 13B injectors.  The last I checked Mazdatrix
had them for around $235 EACH, OUCH!  So, I get a number of used ones for
$30-$50 each and clean and test them   Out of 10 used ones I find 2-3 bad
ones.  One of those $50 injector testers (pulse generators) can give you a
fairly good way of separating the bad/good ones.  The bad ones either don't
give the clicking sound (of injector solenoid) or it is muted compared to a
good injector.  Not a completely fool proof method, but works most of the
time. I have heard that places like RC engineering do a good job of cleaning
and providing good injectors at a reasonable price, but I have no personal
experience with them.

Ed Anderson

Unfortunately Mazda appears to be ripping people off for parts.
Especially electrical parts they don't make like ignition
modules and injectors.

I think Auto Zone or some other auto parts stores probably sell
exactly the same thing for way less money. I sent some email to
Nippon Denso to see if they have an after market catalog.

Another possibility is check with a Toyota dealer and see if
they too are overcharging on injectors. I am willing to
bet the same part is used on a four cylinder 2.5 L or above
Toyota engine.

Paul Lamar
