Hi Paul, do you have a parts weight list for the 13B

Thanks, Steve Carlisle

The flexplate weights vary by generation (and year?).  Here are a few I
have measured:
S4 - 1913g + 120g plate + 122g for 6 bolts
S5 - 1891g + 242g plate and 6 bolts
S5 - 1840g + 256g plate and 6 bolts
S6 - 2251g + (bolts included?)

Here are the numbers for an 87NA automatic rotating assembly:
Front CW + washer - 1274g
Front Rotor "D" - 4609g
Rear Rotor "C" - 4633g
Rear CW - 1861g
flexplate - 1913g + 120g plate + 122g for 6 bolts
eshaft - 6788g

Paul Lamar
